PalmVID WIFI LITE Series DIY Hide it Yourself Hidden Camera Kit

This mini hidden camera kit contains a WiFi IP HDTV Hidden Camera with a pinhole lens plus a HDTV DVR digital video recorder built-in. It includes everything you need to make your own WiFi hidden camera with full remote video accessibility.

View, Playback, and Recording from anywhere in the world over the internet using any windows PC, laptop PC,  iPhones, iPads, Android Smartphones and Android Tablets plus Live Remote View and Playback available on Mac PC's and Laptops Using an Emulator.

The pinhole lens camera only needs a tiny hole to see through so this tiny camera can be hidden even further by hiding it behind an object or inside an object or a box with just a pinhole or slot or other opening for the 1/16 inch pinhole lens.

This DIY kit includes an extra-long camera cable to make installation very easy. This kit also includes your choice of circuit board mounts. There are many ways to configure this kit to work for many applications. View the other images to see some of the options.

• HDTV pinhole lens video camera
• Built-in DVR digital video recorder
• Built-in WiFi transmitter for internet connectivity
• View LIVE or PLAYBACK or RECORD video using any Laptop or Desktop PC or any Android or iPhone or Tablet devices
• Record internally to the built-in DVR (works with up to 512GB Micro SD Cards - not included)
• The wireless WiFi signal lets the camera connect to any home or office internet WiFi network
• The wireless WiFi sigal travels through objects, walls, and floors
• FREE iPHONE and ANDROID PHONE APPS
• NO MONTHLY FEES
• FREE LIFETIME USA-BASED TECH SUPPORT INCLUDED

• MANY PRE-MADE HIDDEN CAMERA MODELS WITH THIS KIT PRE-INSTALLED ARE AVAILABLE TOO!
  CLICK HERE to view all PRE-MADE WiFi-DVR Series Hidden Camera Models



- High Resolution Video Cameras - DVR video recorder built-in - Motion detection recording or continuous recording - View Live/Record/Playback using iPhones, iPads, Android Smartphones and Tablets, Windows PCs and Laptops   WiFi-Lite Series Camera Information Camera Resolution HDTV 720p 1.3 Megapixel Camera Low Light OK Adjustable View Camera Yes Built-in DVR Video Recorder Information Recording Resolution 1280x720 Frames Per Second 20 FPS Time and Date Stamp Yes Motion Activated Recording Yes - Basic Recording Locations Internal: Memory Card External: Phone, Tablet Memory Size up to 512 GB (optional) Recording Time ~ 1 GB per Hour Memory Speed Class 10 or Higher User-Accessible Memory Card Yes Configurable Video Quality Settings Yes Configurable Recording File Length Yes Auto Recycle Storage Overwrite Yes Live Remote Viewing, Recording, and Playback Methods Live Demo WiFi-Lite iPhone, iPad, Android Phone, Tabletet Yes-Advanced App Windows PC, Laptop Yes-Advanced App (with emulator) Mac PC, Laptop Yes-Advanced App (with emulator) Video Playback Yes-Advanced App Power Information Full-Time Wall Power Yes Main/Backup Battery Up to 2 hours with Standard Life Battery Up to 8 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery

Important Notes Regarding Use and Installation:
This kit should only be purchased or used by persons that are completely familiar with the proper handling, installation, and use of circuit-board level components.
The camera ribbon cable and other components of this item are very fragile.
This item may be easily damaged by impacts, electric discharges, static electricity, and short circuits caused by conductive objects or liquids coming into contact with the components.
Parts of this item will generate heat during charging and during normal operation.
This item should not be installed or used near any flammable materials or vapors
This item should not be installed or used in any enclosed area without adequate venting and/or heat sinks.
The use of incorrect power supplies, batteries, chargers, or other power sources may cause overheating and/or permanent damage to this unit.

• MANY PRE-MADE HIDDEN CAMERA MODELS WITH THIS KIT PRE-INSTALLED ARE AVAILABLE TOO!



• This DIY kit uses the same components as the PalmVID WiFi-DVR-LITE Series Pre-Made Hidden Cameras Below:
  (All hidden camera items below have this kit professionally pre-installed)

	DIY-DVR-V2	DIY-DVR-PRO	DIY-WIFI-DVR-LITE
Camera Information
Camera Resolution	HDTV 1080p	HDTV 1080p	HDTV 1080p
Camera Low Light	Good	Very Good	Very Good
Built-in DVR Video Recorder Information
Recording Resolution	HDTV 1080p	HDTV 720p	HDTV 1080p
Frames Per Second	30FPS	24 FPS	24 FPS
Time and Date stamp	Yes	Yes	Yes
Motion Activated Recording	Yes - Basic	Yes - Advanced	Yes - Advanced
Recording Locations	Internal: Memory Card	Internal: Memory Card	Internal: Memory Card External: Phone, Tablet
Memory Size (Capacity)	Up to 512 GB (optional)	Up to 1000 GB (1 TB) (optional)	Up to 1000 GB (1 TB) (optional)
Memory Card Speed	Class 10 or Higher	Class 10 or Higher	Class 10 or Higher)
User Accessible Memory Card	Yes	Yes	Yes
HDTV Recording Rate	~ 1.5 GB per Hour	~ 2 GB per Hour	~ 1 GB per Hour
Field of View:	80°	90°	90°
Loop/Recycle Recording	No	Yes	Yes
Remote Control:	Yes	Yes	Remotely Controlled over App
Warranty:	12 Months	12 Months	12 Months
Live Remote Viewing, Recording, and Playback Methods
iPhone, iPad, Android Phone, Tablet	No	No	Yes - Free Advanced App
Windows PC, Laptop	Yes (Via USB)	No	Yes - Free Advanced App (with free emulator)
Video Playback	Computer	Computer	Computer, Mobile App
Internet Live View (WiFi):	No	No	Yes
Live View Methods:	USB to PC	TV or Monitor	Computer,iPhone, iPad,or Android Smart phones and Tablets
Power/Battery Information
AC/DC Wall Power Supply	Yes (included USB cord)	Yes (included AC cord)	Yes (included USB cord)
Battery Info (More Info in the columns below)	Included rechargeable battery with up to 4 hours total motion- activated recording time and standby time	Included rechargeable battery with with up to 100 Days total motion-activated standby time in PIR mode	Included rechargeable battery with up to 4 hours total motion- activated recording time and standby time
Battery Option Information: Recording time (Continuously)	Up to 2 hours with Standard Life Battery Up to 8 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery	Up to 2 hours with Standard Life Battery Up to 8 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery	Up to 2 hours with Standard Life Battery Up to 8 hours with Extra-Life Battery Up to 12 hours with Super-Life Battery
Battery Option Information: Recording time (Motion Activated)	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery	Up to 4 hours with Standard Life Battery Up to 16 hours with Extra-Life Battery Up to 32 hours with Super-Life Battery
Battery Option Information: Recording time (PIR Motion Activated)	N/A	Up to 7 days with Standard Life Battery Up to 50 days with Extra-Life Battery Up to 100 days with Super-Life Battery	N/A
